8" Pitch Conveyor Chain Links
3939-B4 Chain
Model Specifications
Print
| Part No. | PLI C/L No. | Pitch P | Inner Plates b1 | Pin Dimensions d2 | Pin Dimensions L | Plate Dimensions h2 | Plate Dimensions d3 | Plate Dimensions d4 | Plate Dimensions J | Plate Dimensions K | Plate Dimensions T | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part No. : CC3939B4CL | PLI C/L No. : ECC C/L 3939-B4 | Pitch P : 8 | Inner Plates b1 : 1.063 | Pin Dimensions d2 : 0.437 | Pin Dimensions L : 1.929 | Plate Dimensions h2 : 1.125 | Plate Dimensions d3 : 0.283 | Plate Dimensions d4 : 0.283 | Plate Dimensions J : 1.5 | Plate Dimensions K : 4 | Plate Dimensions T : 0.157 | Add to cart | ||
| Part No. : CC3939B4CLPLI | PLI C/L No. : PLI C/L 3939-B4 | Pitch P : 8 | Inner Plates b1 : 1.063 | Pin Dimensions d2 : 0.437 | Pin Dimensions L : 1.929 | Plate Dimensions h2 : 1.125 | Plate Dimensions d3 : 0.283 | Plate Dimensions d4 : 0.283 | Plate Dimensions J : 1.5 | Plate Dimensions K : 4 | Plate Dimensions T : 0.157 | Add to cart | ||
